Huawei – 16-Port GPON Board for High-Performance

Key Features

• GPON Ports: 16 GPON SFP ports supporting multiple ONTs

• Speed:

  • Upstream: 1.244 Gbps

  • Downstream: 2.488 Gbps

• Supported SFP Module Classes: B+ (28 dB), C+ (32 dB), and C++ (35 dB)

• Maximum Reach:

  • Up to 20 km for Class B+

  • Up to 40 km for Class C+ and C++

• Split Ratio:

  • 1:64 for Class B+

  • 1:128 for Class C+/C++

• MAC Addresses Supported: 32,768

• Guaranteed Bandwidth: 1,238,784 kbit/s

• Physical Dimensions: 237 mm (W) x 22 mm (H) x 395 mm (D)

• Power Consumption: Typical 38 W

Advanced Protocols and Features

• IPv6 support

• Forward Error Correction (FEC)

• 4-level Hierarchical Quality of Service (HQoS)

• Variable-length OMCI (ONT Management and Control Interface)

• Committed Access Rate (CAR) Group

• Virtual MAC (VMAC) modes N:1 / 1:1

Installation and Usage

The H805GPFD board is designed to be easily installed in compatible Huawei OLT chassis slots. It supports firmware upgrades to ensure optimal performance and security. It is widely used by operators to deliver stable, high-bandwidth FTTH services.

Summary

The Huawei H805GPFD is a robust and reliable 16-port GPON board ideal for modern FTTH network deployments requiring high bandwidth and extended reach. Its support for multiple SFP classes provides flexibility for diverse network needs.
